• Purpose: Solar panel
• Power protection features: Over voltage, Under voltage, Over power, Overheating, Overvoltage protection
• Efficiency: 93%
• Power supply type: Indoor/outdoor
• DIP Switch: Yes
• Connectivity: Ethernet
• Power current type: DC/AC
• International Protection (IP) code: IP21
• Cross-section connections supported: 50 mm2
• Three-phase and parallel operation : Yes

• Material: ABS, Steel
• Number of VE. Bus ports: 1
• Built-in display: No
• Product colour: Blue

• Power at zero load: 10 W
• Input voltage: 9.5 - 17 V
• Output power at 25°C: 1300 W
• Peak power: 2800 W
• Output power at 65°C : 800 W
• Ongoing charging of the starter battery: 1 A
• Frequency range: 45 - 65 Hz
• Charging voltage (absorption) : 14.4 V
• Output voltage: 230 V
• Charging the current battery: 70 A
• DC input voltage: 12 V
• Apparent power: 1600 VA
• Output power at 40°C : 1100 W
• Frequency: 50 Hz
• Charging voltage (liquid): 13.8 V
• AC input voltage: 187 - 265 V

• Operating relative humidity (H-H): 0 - 95%
• Operating temperature (T-T): -40 - 65 °C

• Depth: 120 mm
• Height: 470 mm
• Width: 265 mm
• Weight: 10.2 kg
